Description
Features
- Waterproof or weatherproof
- Supports EM/TK4100, EM4102 cards
- Wiegand, TTL, and RS232 interface options
- External antenna for extended range
- Low power consumption at DC 5V or 3.3V
Technical Specifications
| Frequency | 125 KHz |
| Supporting Card | EM4100 or TK4200 or EM4200 card |
| Interface | Wiegand26, TTL, RS232 |
| Power Supply | 5 V & 3.3 V |
| Card Reading Distance | 3.15 in (> 8 cm) (depending on label size) |
| Operating Temperature | 14 °F to 158° F (-10 °C to 70 °C) |
| Antenna | External, optional specifications |
| Dimensions | 1.54 in x 0.75 in x 0.35 in (3.9 cm x 1 cm x 0. cm) |
| Weight | 1.411oz (40g) |
