Features
- AM 125 KHz contactless proximity reading RFID module
- Either Wiegand 26 or ASCII output determined by pin assignment
- Read only for EM cards, and the data are sent by Data 0 and Data 1
- Lower cost with effective performance
- Compact size
- Including antenna
Technical Specifications
| Transmitting Frequency | AM 125 KHz |
| Protocol | ISO 1443A, ISO 14443B, ISO 15693 |
| Power Consumption | DC 3.3 V to 5.4 V DC 12 V (Optional) |
| I O | 25 mA sink source |
| Storage Humidity | 5 % to 95 % RH |
| Read Range | 1.9 in to 2.3 in (5 cm to 6 cm) |
| Dimensions | 1.02 in x 0.35 in 26 (Diameter) x 9 (H) mm |
| Storage Temperature | 68 °F to 185 °F (20 ℃ to 85 ℃) |
| Operating Temperature | – 14 °F to 167 °F (- 10 ℃ to 75 ℃) |
