| Operating Frequency |
13.56 MHz |
| Dimension |
11.3 in X 10.3 in X 0.6 in (25.4 mm X 263 mm X 17 mm) |
| Case Material |
Engineering Plastic ASA, Aluminum Metallic Shield |
| RF Input Power |
2 W |
| Cable |
9.8 ft (3 m) Built-In Coaxial Cable Include SMA Connector |
| Reader Compatibility |
Invengo Medio L40, Medio Pxxx Family and Medio Lxxx Family |
| Protection Level |
IP65 |
| Interface |
SMA (Female) |
| Vswr |
<1.3:1 |
| Antenna Impedance |
50 omega |
| Case Materials |
Metallic Shield |
| Power Supply Mode |
Passive |
| Chip Type |
Read/Write |
| Gain |
9 dBi |
| Weight |
3.74 lb (1.7kg) |
