| Distance |
0.33 ft to 131.23 ft (0.1 m to 40 m) |
| Accuracy |
±1.64 in (±5 cm) |
| Measure Angle |
360° |
| Angle Resolution |
0.27° to 0.6° |
| Measure Frequency |
9.2 kHz |
| Scan Frequency |
7 Hz to 15 Hz (adjustable) |
| Drive |
Built-in DC brushless motor |
| Alert Area Supports Shape |
Circle, rectangle, polygon |
| Spindle Speeds |
400 to 900 revolutions |
| Self-check Alarm |
YES |
| Mode |
The output mode and port can be set according to customer |
| Supply Voltage |
DC 10 V to 26 V |
| Power Dissipation |
<5 W |
| Laser |
IEC Class 1 & FDA Class 1 |
| Working Temperature |
14 ℉ to 122 ℉ (-10 ℃ to +50 ℃) |
| Storage Temperature |
-4 ℉ to +140 ℉ (-20 ℃ to +60 ℃) |
| Size |
3.46 in x 2.68 in x 2.32 in (88 mm x 68 mm x 59 mm) |
| Weight |
0.73 lb (330 g) |
