Description
Features
- Wide spectral range
- High sensitivity
- Through-hole mounting
- Durable construction
Technical Specifications
| Type | Photodiode |
| Spectral Range | 800 nm to 1700 nm |
| Mounting Type | Through Hole |
| Output | Analog |
| Material | InGaAs |
| Breakdown Voltage | 30 V to 200 V |
| Sensitivity | 0.6 A or W at 1550 nm |
| Gain | 10^4 |
| Noise Equivalent Power | 2.5 x 10^-14 W or √Hz |
| Response Time | 1 ns |
| Capacitance | 2 pF |
| Responsivity | 0.5 A or W @ 1310 nm |
| Dark Current | 1 nA |
| Temperature Coefficient | -0.45 % or °C |
| Operating Temperature | -4 °F to 131 °F (-20 °C to 55 °C) |
| Weight | 1.76 oz (50 g) |
