Description
Technical Specifications
| Laser wavelength | 905 ±20 nm |
| Laser channels | 1 |
| Field of view | 270° |
| Beam divergence | longitudinal 5.8 mrad transversal 0.58 mrad |
| Angle resolution | 0.225° |
| Scanning frequency | 10 Hz to 25 Hz |
| Working distance (based on reflectivity) | 0.66 ft to 6.56 ft (0.2 m to 2 m) 2% reflectivity 0.66 ft to 26.25 ft (0.2 m to 8 m) 10% reflectivity 0.66 ft to 32.81 ft (0.2 m to 10 m) 80% reflectivity 0.66 ft to 32.81 ft (0.2 m to 10 m) reflector |
| Distance resolution | 1 ms |
| Absolute Accuracy | <±1.97 in (50 mm) |
| Repeat Accuracy | <0.79 in (20 mm) |
| Ethernet connection | 100 Mbps Ethernet |
| Scanning rate | 16 K to 40 K pts |
| Connection | 5 pin, M 8×1, B-code, Female, 6.56 ft (2 m) (Power) 4 pin, M8x1, A-code, Female, 6.56 ft (2 m) (LAN) |
| Horizontal error (horizontal) | ≤±0.5° |
| Responding time | 130 ms 10 Hz |
| Switching outputs | 1 ea |
| Operating voltage | 12 V to 30 V DC |
| Degree of protection | IP 66 |
| Indicator status | RGB x 4 |
| Ambient light limit | <80000 LUX |
| Mounting | Bottom, Back |
| Power consumption | 5 w 77 ℉ (25 °C) |
| Operating temperature | 14 ℉ to 122 ℉ (-10 ℃ to 50 ℃) |
| Storage temperature | -22 ℉ to 158 ℉ (-30 ℃ to 70 ℃) |
| Mechanical dimensions | ≤2.36 in x 2.36 in x 3.35 in (60 mm x 60 mm x 85 mm) |
| Weight | 0.99 lb (450 g) |
