| Wireless Standards |
LoRa |
| Frequency Band |
850MHz to 930MHz (customized) |
| Operating Humidity |
10% to 90% RH |
| Power Supply |
12V to 24V DC |
| Transmitted Power |
30 dBm |
| Function |
LoRa communication |
| LoRa Chip Solution |
LLCC68 |
| Radio Power |
30 dBm / 27 dBm / 24 dBm / 21 dBm |
| Radio Speed |
62500 / 38400 / 19200 / 19600 / 4800 / 2400 |
| Transmission Length |
200 Bytes |
| Work Mode |
Normal mode or relay mode |
| Rated Voltage |
DC 12V (working range: DC 12–24V) |
| Rated Power |
<5W |
| Power Protection |
Anti-static, anti-surge, anti-reverse connection |
| Work Mode |
Master |
| Baud Rate |
115200 / 9600 / 4800 / 2400 |
| Working Temperature |
-4°F to +158°F (-20°C to +70°C) |
| Storage Temperature |
-40°F to +185°F (-40°C to +85°C) |
