| Application |
Remote Wireless Switch Control |
| Frequency |
433 MHz or 490 MHz |
| Sensitivity |
-132 dBm |
| Modulation |
LoRa |
| Distance Range |
9.32 mile (15 km) |
| Output Power |
5 W |
| Working Voltage |
9 V to 30 V |
| Communication |
One-way |
| Transmit Power (100 mW) |
20 dBm |
| Transmit Power (1 W) |
29.5 dBm |
| Transmit Power (5 W) |
37 dBm |
| Working Voltage (100 mW) |
5 V (3.3 V to 6.5 V) |
| Working Voltage (1 W) |
5 V (3.3 V to 6.5 V) |
| Working Voltage (5 W) |
12 V (9 V to 30 V) |
| Sleep Current (100 mW) |
200 µA |
| Sleep Current (1 W) |
250 µA |
| Sleep Current (5 W) |
7 mA |
| Quiescent Current (100 mW) |
15 mA |
| Quiescent Current (1 W) |
16 mA |
| Quiescent Current (5 W) |
18 mA |
| Emission Current (100 mW) |
130 mA |
| Emission Current (1 W) |
600 mA |
| Emission Current (5 W) |
1.8 A |
| Working Temperature |
-40 °F to 185 °F (-40 °C to 85 °C) |
| Size (100 mW) |
1.94 × 1.26 × 0.12 in (4.95 × 3.22 × 0.32 cm) |
| Size (1 W) |
2.42 × 2.32 × 0.55 in (6.15 × 5.9 × 1.4 cm) |
| Size (5 W) |
3.54 × 4.09 × 1.81 in (9 × 10.4 × 4.62 cm) |
