| Working Voltage |
3.3 V to 3.6 VDC |
| Battery Life |
≥ 2 years |
| Maximum Working Current |
< 300 mA |
| Sampling Interval |
10 min |
| Pressure Range |
0 to 15 MPa (0 to 2175 psi) |
| Pressure Accuracy |
±0.5% FS |
| Temperature Accuracy |
±1.5 °F (±1.5 °C) |
| Pressure Connection |
G1/2 |
| Housing Material |
Aluminum Alloy |
| Ingress Protection |
IP65 |
| Ambient Temperature Range |
-4 °F to 185 °F (-20 °C to 85 °C) |
| Storage Temperature Range |
-40 °F to 185 °F (-40 °C to 85 °C) |
| Housing Dimensions |
6.1 in x 5.1 in x 7.9 in (15.5 cm x 12.9 cm x 20 cm) |
| Antenna Type |
Rod Antenna |
| Weight |
1.1 lb (0.5 kg) |
| Temperature Range |
-22 °F to 302 °F (-30 °C to 150 °C) |
| Antenna |
Rod antenna |
| Working Voltage |
3.3 to 3.6VDC |
| Battery Life |
≥ 2 years (3.6V lithium battery, ER26500 – 9AH, See Note 1) |
| Sampling Interval |
10 minutes (Configurable) |
| Pressure Range |
0 to 15 MPa (Optional) |
| Pressure Accuracy |
±0.5%FS (Customizable) |
| Pressure Connection |
G1/2 (Customizable) |
| Explosion Proof |
ExdIIBT5 Gb (Evidence collection as required) |
| Operating Humidity |
10% to 90% |
| IP Rating |
IP22 |
| Cooling |
Heat dissipation silicone/aluminum |
| Power Consumption |
500mA@5V |
