Description
Overview
Low frequency RFID Reader: 125 KHz, ISO 11784 or 5, 0 cm to 21 cm read range, 5 V, interface UART, animal identification and compact 45 mm X 25 mm.
Technical Specifications
| Frequency | 125 KHz |
| Type | ISO 11784 or 5 |
| Features | Low frequency |
| Working Frequency | 125 KHz or 134.2 KHz |
| Read Range | 0 ft to 0.689 ft (0 cm to 21 cm) |
| Reading Time | <30 mS |
| Recognition Speed | 2 m/S |
| Working Voltage | 5 V |
| Communication Interface | UART |
| Application | animal identification |
| Limit Voltage | -0.3 V to +5.5 V |
| Power Pin To Ground Voltage | -0.3 V to +5.8 V |
| Signal Pin To Ground Voltage | -0.3 V to +3.5 V |
| Maximum IOL Per Pin | 2 mA |
| Relative Humidity | 5% RH to 95% RH |
| Operating Temperature | -4 °F to 185 °F (-20 °C to + 85 °C) |
| Storage Temperature | -4 °F to 176 °F (-40 °C to + 125 °C) |
| Size | 1.77 in by 0.98 in (45 mm X 25 mm) |
