Description
Technical Specifications
| Standard Voltage | DC 9 V to DC 36 V |
| Operating Current | less than 100 mA |
| Card Type | MF1 or CPU |
| User Capacity | Unlimited |
| Blacklist Capacity | 10,000 |
| Data Retention | More than 10 years (after power failure) |
| Address Range | 255 |
| Record Capacity | 80,000 records |
| Reaction Time | <0.3 seconds |
| Sensing Distance | (< 3 cm to 8cm) (depending on antenna size) |
| Product Size (LxWxH) | 3.74 in × 2.20 in × 0.47 in (95 mm x 56 mm x 12 mm) |
| Operating Temperature | -40 °F to 158 °C ( -40 °C to 70 °C) |
| TF Data Export | Support TF card data export function |
| Operating Software | Support with ladder control – set of software |
