Asset Track Pro NFC Module

This NFC Module has a main battery of 4.35 V 5100 mAh, expansion slot of PSAM x 2, sealing of IP 65 and feature of battery life up to 5 hrs.

SKU: ATPNMD-103 Category:

Description

Features

  • High performance 8-core 2.0 GHz processor
  • Built-in Android 8.1 operating system
  • Support reading 1 D and 2 D barcode
  • Support reading and writing of 840 MHz to 960MHz
  • UHF RFID card and label and reading
  • IP 65 protection level
  • Handle main power large capacity battery 4.35 V and 5100 mAh
  • Battery life up to 5 hrs, standby time 72 hrs
  • Support multi-touch and the screen can be operated with water or globe



Technical Specification

CPU ARM Cortex-A53 64 bit 8-core 2.0GHz
Operation System Android 9.0
Memory 4 GB RAM and 64 GB ROM
Expansion Slot PSAM x 2
Touch Panel Industrial touch screen (support glove touch)
Camera 13 MP autofocus with LED fill light
Imager Window Corning Gorilla
Main Battery 4.35 V 5100 mAh Lithium polymer battery
Audio Frequency Built-in microphone
Prompt Vibration Tip and LED Tip or Audio Tip
Vibration motor Built-in programmable vibration motor
Development Tool Android Studio
Programming Language Java
Humidity 57% RH to 95% RH (non-condensation)
Sealing IP 65
Storage Temperature -40 ℃ to 70 °C (18 °F to 139 °F)
Dimension(LxWxD) 6.02 in x 3 in x 4.76 in (153.03 mm x 76 mm x 120.96 mm)
Weight 0.14 lb (0.06 kg)
