Description
Features
- Support Communication via Phone APP
- Support Data Encryption
- Easy and Convenient Operation
- Fast Communication
- Powered by Communication Port
- 32.8 ft (10 m) Communication Distance
Applications
- Solar Energy Systems: Ideal for integrating BLE functionality into solar power management
- Remote Monitoring: Enables Bluetooth-enabled monitoring of solar charge controllers
- Energy Efficiency: Enhances control and data collection for solar setups
Technical Specifications
| Working Voltage | 5 V ± 0.5 V (powered by RJ45 port) |
| Power Consumption | Average: 5 V at 10 mA Peak: 5 V at 60 mA |
| Communication Distance | ≤ 32.8 ft (10 m) |
| Communication Method | RS 485 to Bluetooth |
| Bluetooth Protocol | Bluetooth 5.0 |
| Serial Port Baud Rate | 115200 Bps |
| Enclosure | IP30 |
| Working Temperature | -4 °F to 158 °F (-20 °C to 70 °C) |
| Dimensions | 2.48 in x 0.75 in x 0.54 in (63 mm x 19 mm x 13.8 mm) |
| Net Weight | 0.28 oz (8.0 g) |
