Description
Overview
Asset Track Pro’s H3 Bluetooth Beacon with Motion Sensor, RFID & IP67 H3 Beacon is a long-range, ultra-low-power beacon card designed for commercial advertisements and indoor location-based services. Powered by a Nordic nRF52 ARM® chipset, it offers a range of up to 150 meters, depending on the environment. The beacon features a durable Li-MnO2 battery with a 5-year lifespan, an LED indicator for low battery warnings, and real-time notifications. It supports iOS 7.0+, Android 4.3+, and Bluetooth 5.0 devices, with a transmission range of -40dBm to +4dBm. The card includes a high-quality 50-ohm antenna and customizable case color, with logo imprinting options available. Technical support is provided 24/7.
Features
- Bluetooth Low Energy
- Ultra-low power consumption chipset nRF52 series
- Support 5url broadcasting
- Firmware update Over The Air (OTA)
- Logo and color customizable (MOQ)
- Provided with your own configuration (MOQ 50 units)
- 100% Configurable Parameters via app (Android & iOS)
Technical Specifications
| Battery Model | 3V Lithium Polymer |
| Battery Capacity (Mah) | 850mAh |
| Default Battery Life | 60 months |
| Battery Replaceable | No |
| Max Range | 328 ft (100m)(+4dBm) |
| Waterproof | Yes IP67 |
| Protocols | iBeacon& Eddystone: UID, URL, TLM Eddystone Configuration GATT Service |
| Firmware Updating | OTA |
| Attachment Method | Wearable, 3M double sided sticker |
| Built-In Sensor | Motion LIS3DH |
| Addition Tech | RFID, RGB |
| Size(H X W X L) | 3.34 x 2.12 x 0.20 in (85.6mm x 54.1mm x 5.2mm) |
