Description
Technical Specifications
| Frequency | 125 KHz |
| Protocol | ISO 14443 A |
| Interface | Weigand 26 or 34 Rs 232 Rs 485 |
| Material | ABS |
| Support Cards | TK 4001 or EM 4100 etc |
| Read Range | 0.09 ft to 0.26 ft (3 cm to 8 cm) |
| Operating Voltage | DC 9 V to 16 V |
| Consumed Current | <60 mA |
| Reader Interval | <0.5 S |
| Format | Wiegand 26 Wiegand 34 RS 232 RS 485 |
| Distance Of Transmission | WG 26 or 34<100 M RS 232<10 M RS 485<1200 M |
| Reading Distance | 0.06 ft to 0.16 ft (2 cm to 5 cm) |
| Consumed Current | <60 mA |
| Power Supply | 12 V DC |
| Card Type | EM Card 125 KHz |
| Status Indication | LED |
| Operating Temperature | -13 °F to 167 °F (-25 ℃ to + 75 ℃) |
| Size | 2.36 in X 1.57 in (60 mm X 40 mm) 3.14 in X 1.69 in X 0.51 in (80 mm X 43 mm X 13 mm) |
