| CPU |
i7-4500U |
| GPU |
HD Graphics |
| Memory |
1 x SO-DIMM slot, support DDR3L 1333 or 1600MHz up to 8GB |
| Storage |
1 x Full-height Mini PCIe mSATA |
| Display |
2 x HD-MI |
| Audio |
1 x Headphone, 1 x Microphone |
| Gigabit Network |
2 x RJ45 10 or 100 or 1000Mbps LAN |
| WLAN or Bluetooth |
1 x Half-height Mini PCIe WLAN or Bluetooth or 3G SIM |
| USB |
2 x USB 2.0, 4 x USB 3.0 |
| COM |
6 x RS232 |
| Display |
2 x HD-MI |
| WLAN |
Optional |
| Power Supply |
DC IN |
| BIOS |
AMI BIOS |
| OS |
Win-7 or 8 or 10 |
| Power |
Adapter 12V or 5A 60W |
| Cooling |
Fanless, passive cooling |
| LED Light |
Power LED, HDD LED |
| Button |
Power button |
| Mounting |
VESA mount (optional) |
| Storage Humidity |
5% to 95%RH, non-condensing |
| Operation Temperature |
32°F to 122°F (0°C to 50°C) (industrial grade components) |
| Storage Environment |
-4°F to 158°F (-20°C to 70°C) |
| Dimensions |
4.37 in × 7.36 in × 1.97 in, (111mm × 187mm × 50mm) |
