| Type |
Temperature and Humidity Sensor |
| Mounting Type |
Temperature and Humidity Sensor |
| Use |
Temperature and Humidity Sensing |
| Theory |
Resistance Sensor |
| Output |
Switching Transducer |
| Termination Style |
Wire Leads |
| Connector |
Molex |
| Probe Material |
Stainless Steel SS304 |
| Series |
Temperature and Humidity Sensor |
| Resistance (R25 °C) |
100K Ohm |
| Accuracy |
±0.5 °C (±0.9 °F) |
| Additional Accuracy Options |
±1% or ±5% |
| B Value |
3950K ±1% |
| Current |
0.5 mA |
| Probe Types |
Stainless Steel or PE or PVC |
| More Types |
SHT10, SHT11, SHT15, SHT21, SHT25 etc. |
| Shell Material |
Stainless Steel or Plastic |
| Cable Material |
PVC or Silicone (customizable) |
| Terminal Type |
Tinning or Stereo Plug (customizable) |
| Application |
Agricultural Monitoring, Food Cold Chain, Fresh Air Systems, Industrial Monitoring |
| Humidity Range |
0 to 100% RH |
| Humidity Accuracy |
±3% RH or ±2% RH or ±1.5% RH (chip dependent) |
| Temperature Accuracy |
±0.54 °F (±0.3 °C) or ±0.36 °F (±0.2 °C) or ±0.18 °F (±0.1 °C) |
| Switching Temperature |
-40 to 221 °F (-40 to 105 °C) |
| Operating Temperature Range |
-40 to 221 °F (-40 to 105 °C) |
| Temperature Range (Sensor Element) |
-40 to 1112 °F (-40 to 600 °C) |
