| Accuracy |
0.5 % FS |
| Sensitivity |
1.0 mV/V to 1.5 mV/V |
| Non-linearity |
0.3 % |
| Relative creep over 30 min |
0.05 % |
| Temperature influence on sensitivity |
0.05 % FS / 18 °F (0.05 % FS / 10 °C) |
| Temperature influence on the zero signal |
0.05 % FS / 18 °F (0.05 % FS / 10 °C) |
| Zero output |
± 1.0 % FS |
| Input resistance |
350 ± 20 Ω |
| Output resistance |
350 ± 3 Ω |
| Insulation resistance |
> 5000 MΩ |
| Reference excitation voltage |
10 V DC |
| Limit force |
150 % |
| Breaking force |
> 300 % |
| Material |
Stainless Steel |
| Mode of connection |
Input+: Red, Input-: Black, Output+: Green, Output-: White |
| Level of protection |
IP66 |
| Operating temperature range |
-4 °F to 149 °F (-20 °C to 65 °C) |
| Nominal (rated) temperature range |
14 °F to 113 °F (-10 °C to 45 °C) |
| Reference temperature |
73.4 °F (23 °C) |
| Mass |
21.16 oz (600 g) |
