| Material |
Stainless steel, plastic |
| Accuracy |
±0.5% FS |
| Application |
Water, oil, air, steam, and fuel pressure measurement |
| Pressure Range |
0.1 MPa to 250 MPa |
| Measured Media |
Gas, water, steam, fuel |
| Supply Voltage |
3.6 V DC (battery-powered) |
| Battery Capacity |
19,000mAh |
| Output |
LoRa, LoRaWAN, WMBus |
| LoRaWAN Frequency |
433MHz, 868MHz, 915MHz, 923MHz |
| Communication Protocol |
Standard loRaWAN agreement |
| Scale Range |
0.1 Mpa to 60 MPa (inner arbitrary interval) |
| Precision Grade |
0.5% FS |
| Overload Capacity |
300% |
| Service Life |
>9 million pressure cycles |
| Installation Screw |
M20×1.5, G1/2, etc. |
| Protection Grade |
IP65 |
| Working Temperature |
-4°F to 140°F (-20°C to 60°C) |
