Description
Overview
Asset Track Pro Lidar Mapping Drone has to lead to significant advancements in size, weight, and strength optimization, resulting in a highly versatile drone. Crafted with high-strength aviation aluminum, the drone boasts a lightweight and compact design, offering impressive strength and portability. Its intelligent battery system not only prioritizes weight efficiency but also ensures the drone’s safety and enables extended flight operations. Equipped with flexible connectors, gimbal sharing capabilities, and multiple power supply interfaces, it can seamlessly accommodate a wide array of payloads and applications. Additionally, its robust secondary development capabilities empower users to tailor the drone to their specific needs, making it a standout choice for various fields and environments.
Features
- Advanced Open-Source Flight Control
- Redundant IMUs for Reliability
- GPS with Differential Positioning
- Waterproof and Dust-Proof Design
- Intelligent Battery Management
- Ultra-Light Carbon Fiber Props
- Efficient T-DRONES Customized Motor
- High-Performance ECS for Improved Efficiency
Technical Specifications
| Wheelbase | 27.52 in (699 mm) |
| Maximum Ascent Speed | 5 m / s |
| Maximum Descending Speed | 2 m / s |
| Maximum Horizontal Flight Speed | 12 m / s |
| GPS Hover Accuracy | Vertical: ± 0.5 m Horizontal: ± 2.5 m |
| Hover Time | 71 m to 60 m |
| Maximum Tolerable Wind Speed | 10 m / s |
| Working Temperature | 59 °F to 122 °F (15 ℃ to 50 ℃) |
| Propulsion System | T-MOTOR |
| Control System | PIXHAWK |
| Dimensions (Unfolded) | 22.63 in x 23.03 in x 16.14 in (575 mm x 585 mm x 410 mm) |
| Weight of Drone (Without Battery) | 2.53 lb (1.15 kg) |
| Weight of Drone (With Battery) | 7.16 lb (3.25 kg) |
| Weight of Battery | 4.62 lb (2.1 kg) |
| Max Take-off Weight | 9.36 lb (4.25 kg) |
