| CPU |
ARM Cortex-A7, 528 MHz |
| Memory |
128 MB DDR3 RAM, 128 MB Flash |
| Extendable Storage |
1 × Micro SD Slot |
| Antenna Connector |
2 × 50 Ω SMA Connectors |
| SIM Slots |
2 (Mini SIM-2FF) |
| WiFi Standards |
IEEE 802.11 b/g/n, 2.4 GHz |
| WiFi Modes |
AP or Client mode |
| Serial Interface |
1 × RS232 |
| Connector |
3.5 mm Terminal Block |
| Baud Rate |
300 bps to 230,400 bps |
| Power Supply |
DC 9 to 48V input |
| Power Consumption |
<5W |
| Dimensions |
5.35 × 3.86 × 1.46 in (13.6 × 9.8 × 3.7 cm) |
| Operating Temperature |
-40°F to 158°F (-40°C to 70°C) |
| Storage Temperature |
-40°F to 185°F (-40°C to 85°C) |
| Humidity |
5% to 95% non-condensing |
| Ethernet Ports |
2 × 10/100 Mbps |
| Installation |
Wall or DIN rail mount |
