Description
Features
- Default configuration Quad-core 1.5G + 2G RAM + 16G ROM + 1D + Wi-Fi + BT4.1 + GPS + FDD-TLE 4G/WCDMA/GSM + phone +
- 8M pixel Camera barcode scanner (Support google play store)
- 2D, NFC, LF (125K) for option
- Compact and Portable Ergonomic Design with wrist strap
- Safe droid OS (Android 7.0) Highly optimized Android operating system
- OM mega pixel camera
- High capacity 4200mA large capacity battery for critical requirements
- Pogo Pin interface for convenient charging with optional charge cradle
- Industrial rugged design, waterproof and protection grade (IP66)
Technical Specifications
| Frequency | 125kHz, 134kHz (FDX-B or HDX) |
| Protocol | ISO11784 or ISO11785, ISO18000-2 |
| Range | 1.18in to 3.15in (3cm to 8cm) |
| OS | Android 7.0 |
| CPU | ARM CORTEX-A53 64bit Quad-Core 1.3G |
| RAM | 2G RAM |
| Flash ROM | Standard 0.56oz (16g) AND Flash Storage |
| WI-FI | Support IEEE802.11 a or b or G or n protocol, it need effective wireless LAN signal cover |
| FDD/TDD-LTE 4G | TDD-LTE (B38, B39, B40, B41), FDD-LTE (B1, B3) |
| WCDMA 3G | B1, B2, B5, B8 |
| GSM 2G | GSM or edge or GPRS (850,900,1800,1900MHz) |
| Bt | Support bt 2.0+EDR or 3.0+HS or 4.1+HS, transmission distance is 5m to 10m |
| Camera | 8MP autofocus camera with flash |
| GPS | Support A-GPS |
| Operating | -4°F to 122°F (-20°C to 50°C) |
| Storage Temperature | -13°F to 158°F (-25°C to 70°C) |
| Environment Humidity | 5%RH to 95%RH (no condensation) |
| Drop Specifications | 6 sides can bear impact from 4.92ft (1.5m) drop to cement floor in the range of operating temperature |
| Roll Specifications | 1000 times or 1.64ft (0.5m), roll on 6 sides contact area |
| Sealed Environment | IP65 |
| 1D Laser Scanner | Symbol 955, HoneywellN4313, Mingde966 |
| Resolution | 4Mil minimum width |
| Ambient Light | 10000ft.candles(107640 lux) |
| Scanning Speed | 104(±)12 or sec (both way) |
| Scanning Angle | 47o±35o(Standard) or 35o±3o (narrow angle) |
| Support Bar Code Type | UPC or EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Coda bar, MSI, RSS |
| CMOS Scanner | Honeywell N6603, Newland 3096 |
| The Sensor Resolution | 752 (level) × 480 (vertical) pels (Gray level) |
| Ambient Light | All dark 9000ft.candles or 96900 lux |
| Focus Element (VLD) | 655nm ± 10nm |
| Support Bar Code Type | PDF417, MicroPDF417, Composite, RSS, TLC-39, Data matrix, QR code, micro QR code, Aztec, Maxi Code; Postal Codes: US POSTNET, US Planet, UK Postal, Australian Postal, Japan Postal Dutch Postal (KIX)3 |
| HF RFID Reader (Optional) Frequency Protocol Range |
13.56MHz ISO14443A or B, ISO15693 1.18in to 3.15in (3cm to 8cm) |
| NFC Reader (Optional) Frequency Protocol Range |
13.56MHz ISO or IEC 18092 (ECMA 340) 0.79in to 1.57in (2cm to 4cm) |
