Description
Technical Specifications
| Type | Motion and Position sensor |
| Features | Industry grade single LiDAR |
| Theory | Rotating mirror type |
| Output | RJ45, USB |
| Horizontal FOV | 270o |
| Operating Voltage | 6 to 36V |
| Weight | 5.64 oz (160 g) |
| Protection Distance | 0 to 590.55 in |
| Scanning Frequency | Max 20Hz |
| Data Sample Rate | 18 Khz |
| Power Consumption | ≤ 2.5 W |
| Operating Temperature | -13o F to 140 oF (-25 ℃ to 60 ℃) |
| Storage Temperature | -40 o F to 167 oF(40 °C to 75 °C) |
| Wavelength | 940 nm |
| Dimension | 2.36 in x 2.36 in x 3.15 in (59.94 mm X 59.94 mm X 80.01 mm) |
