Description
Technical Specifications
| Transmit Frequency | 13.56 MHz |
| Protocol | ISO 14443A |
| Housing Material | UL94 Polycarbonate |
| Communications | Wiegand, Clock-and-Data, Open Supervised Device Protocol (OSPD) via RS485 |
| Environmental Rating | Indoor/Outdoor IP55; IP65 if installed with optional gasket, IP65 |
| Panel Connection | Pigtail or Terminal Strip, Terminal Strip |
| Certifications | UL294/cUL (US), FCC Certification (US), IC (Canada), CE (EU), RCM (Australia, New Zealand), SRRC (China), KCC (Korea), NCC (Taiwan), iDA (Singapore), RoHS, MIC (Japan)4 |
| Reader Management | Reader Manager Mobile App for Mobile Access / OSDP infield upgrade, configuration, firmware upgrade and diagnostics |
| Housing Material | UL94 Polycarbonate |
| Operating Temperature | -31º F to 150º F (-35º C to 65º C) |
| Storage Temperature | -67º F to 185º F (-55º C to 85º C) |
| Operating Humidity | 5 % to 95 % relative humidity non-condensing |
| Product Weight (Pigtail) |
3.9 oz (113g) 5.3 oz (151g) 7.7 oz (220g) 9.0 oz (256g) |
