Description
Features
- 125KHz Operating Frequency
- Available to be embedded into individual items
- Read CSN card number only
- Different output formats
Technical Specifications
| Frequency | 125 KHz |
| Supporting Card | EM4100 or TK4200 or EM4200 Card |
| Interface | Wiegand26, TTL ,RS232 |
| Power Supply | 5V & 3.3V |
| Card Reading Distance | > 3.15 in Depending on label size and surroundings) |
| Operating Temperature | 14°F to 158°F (10ºC to 70ºC) |
| Antenna | External, Variety of optional specifications |
| Dimension | 1.54 in x 0.75 in x 0.35 in (39mm x 19mm x 9mm) |
