Description
Technical Specifications
| Frequency | 125 KHz |
| Protocol | ISO 14443A |
| Card Type | 125 KHz EM4100 or TK4001 |
| Interface | Wiegand 26 or 34 or UART |
| Read Range | 0 in to 1.97 in (0 mm to 50 mm) |
| Reader Interval | 0.5 S |
| Voltage | DC 3.3 V or 5 V |
| Application | Door Access Control System |
| Power Supply | DC 5 V |
| PCB Size | 1.20 in x 0.79 in (30.5 mm x 20 mm) |
| Coil size | 2.28 in z 1.32 in (58 mm x 33.5 mm) |
