| Output |
NPN or PNP (NC or NO) |
| Supply voltage |
12 V DC to 24 V DC ± 10 %, ripple (P to P): ≤ 10 % |
| Anti ambient light |
Incandescent: ≤ 20,000 lux, daylight: ≤ 30,000 lux |
| Housing material |
PC+ABS |
| Output method |
PNP or NPN |
| Current consumption |
PNP: 900 mW or 900 mW, NPN: 950 mW or 850 mW |
| Material |
Polycarbonate |
| Response time |
25 µs, 50 µs, 100 µs, 300 µs |
| Vibration resistance |
Amplitude: 0.02 in (5 cm), frequency: 10 to 50 Hz |
| Detection accuracy |
> 0.04 in (0.1cm) (fiber-related) |
| Shock proof |
500 m/s² (50G) 3 times each for X, Y, Z direction |
| Light source |
660 nm visible red light |
| High pressure resistant |
1000 V / AC 50 / 60 Hz 60 s |
| Protection circuit |
Surge, reverse polarity, overload protection |
| Connection |
2 m PVC cable |
| Ambient illumination |
Incandescent light: max 20,000 lux, daylight lamp: max 30,000 lux |
| Ambient temperature |
14 °F to 131 °F (-10 °C to 55 °C) (no icing) |
| Cable |
0.08 in (0.2 cm) |
| Size |
1.2 in × 0.4 in × 2.9 in (3.3 cm x 1.1 cm x 7.5 cm) |
| Weight |
3.17 oz (90 g) |
