Wiegand 26 LF RFID Reader with Long Range Proximity – Asset Track Pro

This Wiegand 26 LF RFID Reader supports multiple card types for secure access control with a reading distance of up to 3.28 ft (1 meter).

SKU: ATPSRLR-105 Category:

Description

Product Features

  • USB interface for easy connection
  • Read distance up to 3.28 ft (1 meter)
  • Supports TK4100, EM4200, T5577 cards
  • IP67 rated for waterproof protection
  • Fast reading time of 32 ms



Technical Specifications

Model Number ZW26
Frequency 125 KHz
Material ABS
Type RFID card
Data Transmission Mode Serial
Communication RS232 or RS485 or Wiegand 26
Read Distance Up to 3.28 ft (1 m)
Working Current <100 mA
Power Supply DC 12 V
Protocol Emid
Indication 2 LEDs (red: standby, green: success)
IP Rating IP67
Production Capacity 1,000 pieces per month
Size 9.45 in x 9.21 in x 1.26 in (24 cm x 23.4 cm x 3.2 cm)
