Description
Features
- Android 11 OS: Runs on the latest Android 11 operating system, providing a user-friendly interface,
- Industrial Durability: Constructed with rugged materials to withstand harsh environments
- Spacious 15.6-Inch Display: Offers a generous 15.6-inch high-definition touchscreen,
- Multi-Touch Capacitive Screen Responsive 10-point capacitive touch
- Versatile Connectivity
- Customizable I/O Ports
- Equipped with high-performance processors
- Longevity and Stability
- Easy Maintenance
- Compatibility with Industrial Apps
- Mounting Flexibility: Suitable for VESA mounting, panel mounting, or as a standalone unit, providing installation versatility to fit into any workspace configuration.
Technical Parameters
| Basic Parameter | |
| Sizes | 10.1 inches |
| Resolution | 1280 x 800 |
| Back light | LED |
| Brightness | 300nits, can be customized to 1000nits |
| Dynamic contrast | 1000:1 |
| Touch screen | Capacitive touch |
| Touch point | 10-point touch |
| Respond Time | ≤5ms |
| Luminousness | 85±5% |
| Surface Hardness | 6H |
| Click Lifetime | 50 million times |
| Viewing Angle | R/L:65(Typ.), U/D:65(Typ.) |
| Communication Interface | USB interface |
| Operating System | Android 7.1/8.1/9/11/12 |
| Processor | RK3288 (RK3399/RK3568/A311D optional) |
| RAM | 2GB (4GB/8GB optional) |
| ROM | 8GB eMMC (16GB/32GB/64GB optional) |
| I/O Interface | |
| USB | 2 x USB |
| Display out | 1 x HDMI |
| LAN | 1 x RJ45(Gigabit Ethernet) |
| 4G LTE | 1 x SIM slot(4G module optional) |
| Extended storage | 1 x TF card slot |
| Audio | 1 x Line-out |
| Power | 12V DC power input |
| Environmental Parameters | |
| Operating Temperature | -10－+60 |
| Storage Temperature | -20－+70 |
| Relative Humidity | 20%－90% |
| General Parameters | |
| Outline Dimension | 391 x 240 x 44mm(L x W x H) |
| Display Dimension | 344.5 x 193.5mm(L x W) |
| Mounting Hole Size | 100 x 100mm |
| Shell Material | Metal cover |
| Installation Type | Wall-Mounted, Desktop, VESA |
Optional Configuration
| Motherboard Optional | RK3288 | RK3399 | A311D | RK3568 |
| Version Optional | Android 7.1 | Android 8.1/9/11 | Android 9 | Android 11/12 |
| RAM Optional | 2GB/4GB | 2GB/4GB | 4GB/8GB | |
| ROM Optional(eMMC) | 8GB/16GB/32GB | 16GB/32GB/64GB | 16GB/32GB/64GB | |
Ordering Information
Free accessories
| Accessory | Description |
| Embedded buckle | 4 pcs of embedded buckles+ 4 pcs of screws |
| Adapter | 1 pc of 12V/5A adapter |
| Power cord | 1 pc of 1.5m |
| HDMI cable | 1 pc of 1.5m |
| Touch pen | 1 pc |
Optional accessories
| Accessory | Description |
| Power cord | 1 pc of 3m/5m |
| Wall-mount plate | 1 pc of wall-mount plate |
| Desktop stand | 1 pc of desktop stand |
