Description
Technical Specifications
| Frequency | 902 To 928 MHz |
| Gain | 10 DBi |
| Beam Width | Hor 75° Ver 40° |
| Polarization | Circular |
| Protocol | ISO 18000 6C |
| VSWR | ≤ 1.4 |
| F Or B Ratio | ≥ 20 |
| Impedance | 50 Ω |
| Maximum Power | 50 W |
| Lightning Protection | DC Ground |
| Connector | NFemale |
| Packing Size | 17.7 In x 9.84 in x 2.16 in (45 x 25 x 5.5 cm) |
| Gross Weight | 4.3 Lb (1.95 kg) |
| Operating Temperature | -40 °F To 158 °F (-40 to 70 ℃) |
| Dimension | 16.5 In x 9.44 in x 1.18 in x (420 x 240 x 30 mm |
| Net weight | 2.54 Lb (1.15 kg) |
