| Engine |
CM710-1 module based on Impinj E710 |
| Frequency |
865 MHz to 868 MHz or 920 MHz to 925 MHz or 902 MHz to 928 MHz |
| Protocol |
EPC C1 GEN2 / ISO18000-6C |
| Antenna |
Circular Polarized Antenna (4dBi) |
| OS |
Android |
| Applications |
Industrial Grade |
| Internet Connection |
4G |
| RAM+ROM |
4 GB + 64 GB |
| Battery |
4420 mAh |
| Barcode Scanning |
2D |
| Data Wire |
PD |
| Power |
1W (30 dBm, +5 dBm to +30 dBm adjustable) |
| Communication |
WiFi, Bluetooth, 4G, GPS |
| R or W Range |
Up to 49.21 feet (Up to 15 m) (open outdoors, Impinj MR6 tag) |
| Fastest Read Rate |
900+ tags per s |
| Communication Mode |
Pin Connector |
| Screen Size |
5.5 in (13.9 cm) |
| Specification |
6.2 in x 2.9 in x 0.6 in (160.0 mm x 76.0 mm x 15.5 mm) |
