| Interface |
USB, RS232 |
| Type |
RFID card reader |
| Material |
ABS |
| Functions |
Information, encrypt/decrypt, payment, identification |
| Data Transmission Mode |
Serial |
| Application Field |
Government, school, hospital, hotel, E-commerce |
| Frequency |
125kHz and 13.56MHz |
| Supported Protocols |
14443A, 18000-2, 11784, 11758 |
| Operating Systems |
Windows 98, XP32, XP64, 2000, CE, 7, ME, NT, Linux, Vista32, Vista64, Android |
| Supported Card Types |
TK4100, EM4200, T5577, EM4305, Mifare, S50, S70, 14443A cards |
| Reading Distance |
0 cm to 8 cm |
| Reading Time |
< 100 ms |
| Reading Speed |
0.2 s |
| Card Interval Time |
5 s |
| Working Voltage |
5 V |
| Working Current |
100 mA |
| Power Method |
Powered by USB |
| Status Indicator |
2-color LED (red for power, green for status) |
| Built-in Speaker |
Buzzer with LED and buzzer control |
| Humidity |
5 % to 95 % |
| Working Temperature |
-4 °F to 185 °F (-20 °C to 85 °C) |
| Dimensions |
4.13 in x 2.56 in x 0.59 in (10.5 cm x 6.5 cm x 1.5 cm) |
| Weight |
3.88 oz (110 g) |
