Description
Features
- Android 9 os
- 16GB ROM+2GB RAM
- Quad-core 2GHz
- LF 134.2 khz rfid reader
- ISO11784 ,ISO11785 protocol
- Support HDX and FDX-B ear tags reading
- 0 Inch big touch screen
- IP66 Rugged pda terminal
- 4G/3G/GPRS/GPS/Wifi/BT
Technical Specifications
| LF RFID Reader | 134.2khz |
| Protocol | ISO11784 , ISO11785 |
| Tags Type | Able to read HDX and FDX-B two types tags |
| Reading Distance | 0 in to 3.93 in (0 cm to 10 cm) |
| Wireless | 4G/3G/GPRS |
| Wifi | IEEE 802 a/b/g/n/ac |
| BT | Support BT 2.1+EDR/3.0+HS/4.1+HS. Transmission distance 5-10 meters |
| Camera | Rear 8MP |
| Physical Parameter | |
| Dimension | 7.01 in × 3.07 in × 0.94 in (178 mm × 78 mm × 24 mm) |
| Weight | ＜1.10 lb(500 g) |
| Display | 5.0 inch IPS color display |
| Resolution | 720 x 1280 |
| TP | Corning Gorilla glass, supports multi-touch. Supported gloves and wethands |
|
Battery |
Rechargeable polymer battery (3.7 V 4800 mAh) removable Standby time > 350 hours Working time > 12 hours Charging time ＜4H, using standard power adapter and data cable |
| Card Slot | PSAM x 2, Micro SIM card x 1 , TF card × 1、POGO Pin x 1 |
| Interface | Type-C USB x 1, OTG |
| Audio | Speaker (mono), Microphone, Earpiece |
| Keypad | 13 soft silicone buttons |
| Sensor | Gravity sensor, Vibration motor |
| User Environment | |
| Operating Temperature | -4 °F to 131 °F (-20 ℃ to 55 ℃) |
| Storage Temperature | -40°F to 158 °F (-40 ℃ to 70 ℃) |
| Environment Humidity | 5%RH to 95%RH(no condensation) |
| Drop Specification | 6 sides Supports 1.5 meters drops and 30 times to the concrete within the operating temperature |
| Protection Level | IP66 |
| Accessories | |
| Standard | Battery 1pc/data cable 1pc/power charger 1pc/hand strap 1pc/protective film 1pc |
| Optional | Charging cradle |
