Description
Overview
Asset Track Pro Embedded keyboard emulation 13.56 MHz ISO 14443 A Read only NFC RFID module is developed based on international standard protocols. It adopts highly integrated special card reading chip, advanced watchdog and voltage monitoring circuit project design and features a high degree of integration, strong anti-interference ability, small size and more stable performance.
Features
- 13.56 MHz ISO 14443 A IC support
- Keyboard emulation
- Buzzer and LED
- Built-in PCB antenna
- Read RFID UID
Technical Specifications
| Frequency | 13.56 MHz |
| Read or Write Chip | MFRC 500, MFRC 400, MFRC 531, MFRC 632 |
| Baud Rate | 9600 bits per second to 115200 bits per second |
| Working Distance | 0 in to 1.97 in (0 ft to 0.16 ft) |
| Operating Voltage | DC 3.3 V to 5 V |
| Sheathing Material | ABS |
| Power Consumption | < 0.5 W |
| Interface | USB keyboard emulation |
| Protocol | ISO 14443 A |
| Operating Temperature | 14 ºF to 158 ºF (-10 ºC to 70 ºC) |
| Storage Temperature | -4 ºF to 176 ºF (-20 ºC to 80 ºC) |
| Dimensions | 1.77 in x 0.98 in x 0.35 in (45 mm x 25 mm x 9 mm) |
| Weight | 17.6 oz (500 g) |
