Description
Features
- Provides powerful computing power
- High network acceleration capabilities
- Designed for edge computing scenarios
- Meets edge computing IT infrastructure (ECII) standards for edge computing servers.
Technical Specifications
| Internal Storage | Up to 10 x 2.5 SAS / SATA / SSD drives, or 8 x 2.5 NVMe SSDs |
| Processors | 2 Kunpeng 920 processors |
| Form Factor | 2 U edge Rack server |
| Internal Storage | Up to 10 x 2.5” SAS or SATA or SSD drives, or 8 x 2.5” NVMe SSDs |
| PCIe Expansion | 6 full-height half-length PCIe 4.0 x8 slots or 2 full-height full-length PCIe 4.0 x16 slots |
| Power Supply Units | 2 x 1200 W or 2000 W hot-swappable AC PSUs, supporting 1+1 redundancy |
| Power Supply | 100 to 240 V AC, 240 V DC |
| Fan Modules | 4 Hot-swappable fan modules, supporting N+1 redundancy |
| Memory | 16 DDR4-2933 DIMM slots |
| RAID | RAID 0, 1, 5, 6, 10, 50, or 60; supercapacitor for power failure protection |
| LOM Network Ports | 1 LAN on motherboard (LOM) NIC, supporting 4 GE electrical ports, 4 x 10 GE optical ports, or 4 x 25 GE optical ports |
| Fan Modules | 4 Hot-swappable fan modules, supporting N+1 redundancy |
| Number of CPU Threads | 20 |
| Storage Capacity | 500 GB to 1000 GB |
| Operating Temperature | Short-term: 23°F to 131°F (-5°C to +55°C) long-term: 32°F to 113°F (0°C to 45°C) |
| Dimensions (H x W x D) | 3.39 x 17.60 x 19.29 inches (86.1 mm x 447 mm x 490 mm) |
