| Frequency (Low 125KHz) |
125KHz |
| Frequency (High) |
13.56MHz |
| CPU |
MTK6737 1.2GHZ Quad-core |
| Protocol (High) |
ISO14443A or ISO14443B or ISO15693 |
| Protocol (Low 125KHz) |
UEM4100 |
| OS |
Android 7.0 |
| Memory |
2GB+16GB (optional 3GB+32GB) |
| Display |
3.5in LCD 320p x 480p TFT |
| Touch Screen |
Capacitive Touch Screen |
| Communication |
WIFI, GPS, Wireless, 4G or WCDMA or EDGE or GSM, USB, UART |
| External Input |
27 full keyboard input, audio input |
| Output |
Stereo speaker output, video playback |
| SD Or TF |
Max 128GB |
| Standby Current |
Less than 5mAh |
| Working Current |
180mAh |
| Battery Capacity |
3400mAH |
| Battery Voltage |
3.6V to 4.2V |
| Standby Time |
Over 600 hour |
| Working Hours |
Over 8 hour |
| Cell Voltage |
AC 100 V to 240 V, 50 Hz or 60 Hz |
| Charging Current |
1000 mA |
| End-Use Temperature |
5 °F to 145 °F (-15°C to 65°C) |
| Storage Temperature |
-4 °F to 176 °F (-20°C to 80°C) |
| Dimension |
68.8 in x 25.9 in x 11.8 in (17.5 cm x 6.6 cm x 3 cm) |
| Weight |
8.1oz (230 g) |
| Read And Write Distance (High) |
0in to 2.3in (0 cm to 6 cm) |
| Working Current (High) |
Less than 90mAh |
| Read And Write Distance (Low 125KHz) |
0in to 5.9in (0cm to 15cm) |
| Working Current (Low 125KHz) |
80mAh |
| Read And Write Distance (Low 134.2KHz) |
0in to 5.9in (0cm to 15cm) |
| Working Current (Low 134.2KHz) |
80mAh |
| Barcode Type (1D) |
UPC or EAN, Code 128, Code 39, Code 93, Code 11, Interleaved 2 of 5, Discrete 2 of 5, hinese 2 of 5, Codabar, MSI, RSS, Data Options, Serial Interface, Event Reporting |
| Working Current Barcode (1D) |
50mA |
| Barcode Type (2D) |
Code39, PDF417, Data Matrix |
| Working Current Barcode (2D) |
450mA |
