| Wi-Fi Supported Frequency |
2.4G and 5G |
| Standards And Protocols |
Wi-Fi 802.11g, Wi-Fi 802.11b, Wi-Fi 802.11n |
| Encryption Type |
WPA2-Personal, WPA-Personal |
| LAN Ports |
1 |
| Supports WDS |
Yes |
| Supports WPS |
No |
| Wired Transfer Rate |
10 or 100 or 1000 Mbps |
| Function |
Firewall, QoS, VPN |
| Application |
Multi-service |
| WAN Ports |
1 |
| Ethernet |
1 x WAN or LAN (1000 Mbps), 1 x LAN (1000 Mbps) |
| WIFI |
2.4 or 5.8 GHz IEEE802.11b or g or n |
| Serial Port |
1 x RS232 or RS485 |
| Antenna interface |
4 x SMA (5G or 4G), 1 x WIFI 2.4G, 1 x WIFI 5.8G |
| SIM |
1 x SIM or UIM slot, 1.8V or 3V AUTO detection |
| Power |
+9V to +32V（Default adapter: DC 12V or 1.5A） |
| Humidity |
<95% No condensation |
| Temperature |
-22 °F to 167 °F (-30 °C to 75 °C) |
| Dimensions |
4.035 in x 2.894 in x 1.004 in (10.25 cm x 7.35 cm x 2.55 cm) |
| Weight |
8.11 oz (230g) |
