5G Dual Band Wi-Fi With 2GB And Built-In 64-Channel Voice - Asset Track Pro
5G Dual Band Wi-Fi With 2GB And Built-In 64-Channel Voice - Asset Track Pro - Image 2

5G Dual Band Wi-Fi With 2GB And Built-In 64-Channel Voice – Asset Track Pro

High-performance network solution with innovative CPU+NP architecture, 90% bandwidth utilization, SD-WAN readiness, and centralized O&M tools.

SKU: ATPEWF-159 Category:

Description

Features

  • Innovative CPU+NP Heterogeneous Forwarding Architecture for superior L3–L7 service processing.
  • High SD-WAN Performance exceeding industry standards with optimized forwarding capabilities.
  • Comprehensive Application Integration including SD-WAN, cloud management, routing, and more.
  • Intelligent Traffic Steering and optimization based on application SLA, priority, and bandwidth.
  • Bandwidth Utilization Enhancement up to 90% for improved performance.
  • SD-WAN Ready with plug-and-play functionality for easy setup.
  • Automated Network Provisioning via email, USB flash drive, or DHCP.
  • Centralized O&M Tools



Technical Specifications

Network Wireless Lan, Wired LAN
Memory 2 GB
Wi-Fi Dual Band (2.4 GHz And 5 GHz), 802.11b Or g Or n Or ac
DSP (Voice) Built-In 64-Channel Voice
SIC Slots 2
CPU 1.4 GHz, 4 Cores
Flash Memory 1 GB or 512 MB
Fixed LAN Ports 8 x GE RJ45 (Can Be Configured As WAN)
Fixed WAN Ports 1 x GE combo, 1 x GE RJ45, and 1 x 10 GE SFP+ (Compatible With GE SFP)
IPsec Performance (IMIX) 2 Gbit Or s
Console Port RJ45
Maximum Power Consumption 30 W
Maximum PoE Output Power 100 W
Extended Slots (Standard Configuration) 2 x SIC
Power Supply Mode AC Built-In
Heat Dissipation Mode Air Cooling
Number Of Power Modules 1
Rated Input Voltage 100 V To 240 V, 50 Hz/60 Hz
Input Voltage Range 90 V To 264 V, 47 Hz To 63 Hz
Maximum Input Current 2 A
Maximum Output Power 60 W
Type Of Fans Built-In
Long-Term Operating Temperature 32 °F To 113 °F (0 °C to 45 °C)
Dimensions Without Packaging (H x W x D) 1.75 in x 15.35 in x 9.06 in (4.44 cm x 39.0 cm x 22.98 cm)
Weight Without Packaging 6.39 lb (2.9 kg)
