Description
Technical Specifications
| Network | 5G SA or NSA
FDD-LTE or TDD-LTE (cat 4), multi region version available Backward compatible with 3G or 2G |
| Ethernet | 5 x LAN (1000 Mbps) |
| WIFI | 2.4 GHz or 5.8 GHz IEEE802.11b/g/n/ac |
| Serial Port | 1 x RS232
1 x RS485 |
| Input/Output | 2 x DI
1 x DO |
| GNSS (optional) | GPS or GLONASS or BeiDou (Compass) or Galileo or QZSS |
| Antenna interface | 5 X SMA (5G or 4G)
2 x WIFI 2.4G 2 x WIFI 5.8G |
| SIM | 2 x SIM or UIM slot
1.8 V / 3 V AUTO detection |
| Power | 32 to 9 V (Default adapter DC 12 V / 1.5 A) |
| Working Temperature | -22 °F to 167 °F (-30 °C to 75 °C) |
| Environment | < 95% No condensation |
| Dimensions | 7.05 in x 4.88 in x 1.69 in (179 mm x 124 mm x 43 mm) |
| Weight | 21.16 oz (600 g) |
