Technical Specifications
| Frequency Range | 600 MHz to 6000 MHz |
| Gain | 3 dBi or 4.5 dBi |
| Polarization Type | Vertical or Horizontal |
| PIM | ≤-140 dBc |
| Max Power | 50 W |
| Input Impedance | 50 Ω |
| Connector Type | N-Female (4 ports), Customized |
| Dimensions | 14.17 in x 14.17 in x 0.94 in (360 mm x 360 mm x 24 mm) |
| Mounting Kit | Ceiling, Via Hole (Standard) |
| Radome Material and Color | ABS, White, RAL9003 |
| Operational Temperature | -67 °F to 140 °F (-55 °C to 60 °C) |
| Operational Humidity | < 95% |
| Weight | 1.98 lb (0.9 kg) |
