Description
Features
- High performance
- Advanced analysis
- User-friendly
- Rugged design
Technical Specifications
| Use | Long haul |
| Wavelengths (nm) | 1310 ± 20/1550 ± 20/1625 ± 15 |
| Connector Type | FC/PC, SC/PC, (optional LC) |
| Dynamic Range at 20 µs (dB) | 45/45/45 dB |
| Linearity (dB/dB) | ±0.03 |
| Loss Threshold (dB) | 0.01 |
| Loss Resolution (dB) | 0.001 |
| Stable Source Output Power (dBm) | -2.5 |
| Reflectance (dB) | ±2 |
| Distance Range | 0.06 mi to 248 mi (0.1 km to 400 km) |
| Event Dead Zone | 1.64 ft (50 cm) |
| Attenuation Dead Zone | 8.2 ft (250 cm) |
| Sampling Points | Up to 256,000 |
| Pulse Width (ns) | 3 to 20,000 |
| Sampling Resolution (m) | 0.13 ft to 32.8 ft (0.04 m to 10 m) |
| Distance Uncertainty | ± (2.46 ft + 0.0025 % x distance + sampling resolution) |
| Measurement Time | User-defined (maximum: 60 minutes) |
| Typical Real-Time Refresh (Hz) | 4 |
