Description
Features
- Versatile connectivity
- Advanced peripheral support
- Compact and durable operation
Technical Specifications
| Jetson Module Supported | NVIDIA Jetson Orin Nano or Orin NX |
| Networking | 2 x Gigabit Ethernet (10 or 100 or 1000 BAST-T) RJ45 |
| USB | 4 x USB 3.0, 1 x Micro USB |
| Camera | 2 x 4 Lane MIPI Camera Interface FPC Connector |
| Display | 1 x HDMI |
| M.2 KEY M | 2 x M.2 KEY M Interface |
| Other I/O | 1 x CAN, 4 x GPIO, 2 x I2C, 2 x SPI, 1 x I2S, 1 x UART |
| GPU | 1024-Core NVIDIA Ampere Architecture GPU with 32 Tensor Cores |
| CPU | 8-core Arm® Cortex®-A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3 |
| Memory | 16GB 128-bit LPDDR5, 102.4GB/s |
| Storage | Supports External NVMe |
| Video Encode | 1 x 4K60 (H.265), 3 x 4K30 (H.265), 6 x 1080p60 (H.265), 12 x 1080p30 (H.265) |
| CSI Camera | Up to 4 Cameras (8 via Virtual Channels), 8 Lanes MIPI CSI-2, D-PHY 2.1 (up to 20Gbps) |
| Power | 10W to 25W |
