| Display Size |
5.7 in (144.78 mm) |
| Display Resolution |
1280 x 720 |
| Touch Panel |
Multi-touch panel, Corning grade 3 glass toughened screen |
| Front Camera |
5.0 MP |
| Rear Camera |
13 MP Autofocus with flash |
| Speaker |
Built-in 8 Ω or 0.8 W waterproof horn x 1 |
| Microphones |
Sensitivity: -42 db, output impedance 2.2 kΩ |
| Battery Type |
Removable polymer lithium ion batteries |
| Battery Capacity |
3.7 V or 4300 mAh |
| Battery Life |
About 8 hours (standby time > 300 h) |
| CPU Type |
MTK 6762-Octa-core |
| CPU Speed |
2.0 GHz |
| Memory+Storage |
3 GB + 32 GB (optional 2 GB + 16 GB or 4 GB + 64 GB) |
| Operating System Version |
Android 12 |
| NFC |
Support ISO or IEC 14443A protocol, card reading distance: 1.18 in to 1.97 in (3 cm to 5 cm) |
| WIFI Module |
WIFI 802.11 b, g, n, a, ac frequency 2.4 G + 5 G dual band WIFI |
| Bluetooth |
BT4.0 (BLE) |
| 2G/3G/4G |
CMCC 4M: LTE B1, B3, B5, B7, B8, B20, B38, B39, B40, B41 WCDMA 1, 2, 5, 8 GSM 2, 3, 5, 8 |
| Location |
Beidou or GPS or Glonass location |
| Scan Code Function |
NLS-N1 (Optional Honeywell 6603 & zebra se4710 & CM60) |
| RFID Function (LF) |
Support 125K and 134.2K, effective recognition distance 1.18 in to 1.97 in (3 cm to 5 cm) |
| Identification of Second Generation ID Card of Chinese Residents |
Support networked version to decrypt ID card |
| Face Recognition |
Embed face recognition algorithm |
| Infrared Temperature Measurement |
0.39 in to 1.18 in (1 cm to 3 cm) non-contact; temperature measurement accuracy 32.36 °F to 31.64 °F (± 0.2 °C);
Measurement range: 89.6 °F to 109.22 °F (32 °C to 42.9 °C) (human body model); measurement
Time: ≤1S |
| Drop Height |
59.05 in (150 cm) power on status |
| Operating Temp. |
-4 °F to 122 °F (-20 °C to 50 °C) |
| Storage Temp. |
-4 °F to 140 °F (-20 °C to 60 °C) |
| Humidity |
Humidity: 95 % non-condensing |
| Fingerprint |
Fingerprint module: capacitive USB press module |
| Image size: 256 x 360 pi xei；FBI PIV FAP10 certification |
| Image resolution: 508 dpi |
| International standard |
| Authoritative certification |
| Acquisition speed: single frame image acquisition time ≤0.25s |
| Dimensions |
7.01 in x 3.27 in x 0.67 in (178 mm x 83 mm x 17 mm) |
| Weight |
9.88 Oz (280 g) |
| Color |
Black |
