Description
Technical Specifications
| CPU | ARM Cortex A73 octa-core (2.0GHz) |
| GPU | ARM Mali-G72 MP3 |
| RAM | 8 GB |
| Internal Memory | 128 GB |
| External Memory | Micro SD card (T-FLASH card), max 256GB |
| Main Camera | 13.0 MP (AF) with flash LED |
| Sub Camera | 5.0 MP |
| Battery | 9000 mAh |
| Display | 5.5-inch IPS or AFFS 1080 x 920 FHD industrial 500 cd/m² Sunlight Readable |
| Touch Panel | Capacitive or frosted tempered film supports glove touch or spray or active capacitive pen |
| SIM Card | Nano SIM card x 2 |
| TF Card | Micro SD card (T-FLASH card), max 256GB |
| Headphone | 0.14 in (3.5 mm) (CTIA) |
| Charging Interface | Type-C + 2-pin pogo pin |
| Data Interface | USB Type-C (OTG) x 1 |
| RS232 (optional) | RS 232 x 1 |
| Charger | 5 V 2 A to 10 W |
| Navigation | GPS + Beidou + Glonass + AGPS + SBAS (EPO 2.5 m) |
| Color & Material | Black & Yellow; Black & Green; Black & Gray (PC + ABS + TPU) |
| Phone Call | GSM or WCDMA or CDMA 1X or VoLTE |
| 2G Band | GSM (B2 or 3 or 5 or 8) |
| 3G | WCDMA 3.75 G (HSDPA + 42.2 Mbps, HSUPA + 11.5 Mbps), EVDO |
| 3G Band | WCDMA (B1 or 2 or 5 or 8), Evdo: BC0 or BC1, CDMA: BC0 or BC1 |
| 4G | FDD 150 Mbps down, 50 Mbps UP; TDD: 150 Mbps downlink, 50 Mbps uplink |
| 4G Band | TD-LTE (B38 or 39 or 40 or 41); FDD LTE (B1 or 2 or 3 or 4 or 5 or 7 or 8 or 12 or 17 or 20 or 28) |
| Wi-Fi | Dual-band Wi-Fi (2.4 GHz or 5 GHz) single stream 802.11 a or b or g or n or ac |
| Bluetooth | 5.0 Low Energy (LE) |
| Dropproof or IK | MIL-STD-810G or Method 516.6 or Procedure IV & Touch Panel IK05 |
| Waterproof | Class 7 (IEC 60529) |
| Dustproof | Class 6 (IEC 60529) |
| Reliability | MTBF > 5000 h; MTTR < 0.5 h |
| RH | 5 % to 95 % |
| Operating Altitude | Max: 14763.78 ft (4,500 m) |
| Certification | 3C or FCC or CE or ROHS or IP67 (IEC 60529) |
| Language | Multiple languages including English, Spanish, Portuguese, and more |
| OS | Android 9 or 10 or 11 or 13 (Continuous updates) |
| OEM/ODM | Support |
| Package | USB cable, Charger 5V 2A, Introduction manual, Screen protector, Packing box, Toolkit (optional), OTG x 1, SIM Card Ejector x 1 |
| Operating Temperature | -4 °F to 131 °F (-20 °C to 55 °C) |
| Storage Temperature | -40 °F to 158 °F (-40°C to 70 °C) |
| Size | 7.68 in x 3.86 in x 0.87 in (19.5 cm x 9.8 cm x 2.2 cm) |
| Weight | 16.23 oz (460 g) |
