Description
Features
- Lean Screen
- High-speed Printer
- Customer Display
- Shortens the waiting time drastically
- Extensive connectivity
- Various peripheral interfaces
Technical Specifications
| Storage | EMMC 5.0, 8GB; DDR3 2GB; Micro SD Card Slot (Max 32GB) |
| Processor | 32-bit quad-core Cortex-A9 1.6 GHz |
| RAM | 1 GB DDR3 |
| Storage | 8 GB eMMC (expandable via Micro SD up to 32 GB) |
| Main Display | 10.1-inch IPS LCD capacitive touch |
| Main Resolution | 1280 × 800 pixels |
| Secondary Display | 4.3-inch IPS TFT LCD (optional) |
| Secondary Resolution | 800 × 480 pixels |
| Printer Type | 58 mm thermal |
| Print Speed | 70 mm/s |
| Print Width | 58 mm |
| Wi-Fi | 2.4 GHz, 802.11 b, g, n, d, e, h, and i |
| Bluetooth | 4.0 dual mode |
| Ethernet | 10 or 100 Mbps |
| USB Ports | 1 × Type-C, 4 × USB Host, 1 × Mini USB |
| Other Interfaces | Power port ×1, RJ11 ×1, RJ12 ×1, DB9 ×1 |
| Speaker | Built-in 1.5 W |
| Card Voltage | 5 V, 3 V, and 1.8 V support |
| Dimensions | Varies by configuration |
| Weight | Varies by configuration |
| Color | Black and White |
| Material | ABS plastic |
| Power Input | DC power port |
| Indicator Lights | Power LED ×1, Breathing light ×1 |
| Storage Expansion | Micro SD slot (max 32 GB) |
