Overview
RFID and QR code reader: Dual-frequency support, versatile compatibility, extended read ranges, and wide system support.”
Technical Specifications
| Frequency | 125khz, 13.56 mhz (option) |
| Size | 3.385 in × 3.385 in × 0.708 in (8.6 cm × 8.6 cm × 1.8 cm). |
| Voltage | 8 V to 12 V |
| RFID Read Range | 1.181 in to 2.362 in (3 cm to 6 cm) |
| QR Code Read Range | 3.937 in to 7.874 in (10 cm to 20 cm) |
| System Support | Windows XP or 7 or 8 or 10),Linux |
| Communication Port | Wiegand 26 or 34,RS232,RS485,TTL |
| Working Current | 600 mA |
| Symbolizes | 1D or 2D |
| Code Support | Bar code and QR code |
| LED | Blue -working Read- Green |
| Weight | 5.291 oz (150 g) |
