Description
Features
- Ultra Mini Size
- Simultaneous Output
- Multiple Communications Options
- Wide Voltage Range
- Wireless Frequency
- Versatile Applications
- Onboard Antenna
Technical Specifications
| Supported Card Types | MIFare 1 (S 50 or Ultralight) cards |
| Card Reading Distance | Up to 1.96 in (50 mm) |
| Output Port | UART (TTL) and Wiegand 34 output ports |
| Output Mode | Direct serial port output, |
| Protocol | ISO 14443-A |
| Temperature | -4 °F to 185 °F (-20 °C to 85 °C) |
| Dimension | 1.37 in X 0.78 in (35 mm X 20 mm) |
| Weight | 10.58 oz (300 g) |
