Description
Overview
It adopts a highly integrated special card reading chip, advanced watchdog, and voltage monitoring circuit project design and features a high degree of integration, strong anti-interference ability, small size, and more stable performance.
Features
- Compact Design
- Interface Options
- Supported Card Standards
- Working Distance
- High Integration and Stability
- Durable Sheathing Material
- Passive RFID
Technical Specifications
| Frequency | 13.56 MHz |
| Read And Write Chip | MFRC 500, MFRC 400, MFRC 531, MFRC 632 |
| Support Standard | ISO or IEC 14443-A, ISO or IEC 14443-B, ISO or IEC 15693 |
| Interface | RS 232, RS 485, TTL |
| Protocol | ISO 14443-A or B, ISO 15693 |
| Temperature | 14 °F to 158 °F (-10 °C to 70 °C) |
| Dimensions | 1.51 in X 0.74 in X 0.35 in (38.5 mm X 19 mm X 9 mm) |
| Weight | 2.20 lb (1.000 kg) |
