Asset Track Pro 9 DBi Panel UHF RFID Chip Antenna With Long Range Distance – Gain 9 DBi

RFID Antennas with adjustable frequency circular polarization, and various connectors for efficient tracking.

SKU: ATPANT-199 Category:

Description

Technical Specifications

Gain 9 DBi
Working Frequency 902 MHz To 928 MHz (US) Or 865 MHz To 868 MHz (EU)
Polarization Circular
VSWR ≤ 1.3
Beam Width H 70° E 70°
Connector N Outer Female Connector
Protocol ISO 18000 6C
Temperature -40 °F To +185 °F (-40 °C To + 85 °C)
Item Size 10.16 In x 10.16 In x 2.20 In (258 Mm x 258 Mm x 56 Mm)
Net Weight 3.86 Lbs (1.75 kg)
Shell Material ABS
