Description
Technical Specifications
| Frequency | 902 MHz to 928 MHz or 865 MHz to 868 MHz (Adjustable) |
| Protocol | EPC C1 GEN2 or ISO18000-6C |
| Interface Configuration | Standard: RS232 or 485/Wiegand/USB, optional: TCP/IP or Relay or Wifi |
| Work Principle | FHSS or Fixed frequency |
| Work Mode | Timing or Active or Trigger |
| Built-In Antenna | 9 dBi linear polarization |
| Output Power | 0 to 30 dbm ±1 dbm |
| Reading Distance | 0 ft to 39.3 ft (0 m to 12 m) (depends on tag or environment) |
| Tag Displacement speed | ≤ 62.1 mi (100 km) per H |
| Reading Speed | > 20 times per s |
| Power Supply | +9 V to +25 V or >2 A |
| Power Dissipation | <3W per H |
| Work Tip | Buzzer |
| Temperature Range | 14 ℉ to 131 ℉ (-10 ℃ to +55 ℃) |
| Humidity Range | 20 % to 95 % |
| Dimension | 10.04 in x 10.04 in x 1.65 in (255 mm x 255 mm x 42 mm) (Exclude bracket and external wires) |
| Gross Weight | 5.07 lb (2.3 kg) (incl. packing) |
